| Cutting Diameter (DC/DCX) | 24 mm | Usable Length (LU) | 39.37 mm |
| Cutting Diameter (DC) | 12.2174 mm | Corner Radius (RE) | 5 mm |
| Cutting Item Count (CICT) | 2 | Coolant Supply Property (CSP) | Coolant Thru |
| Depth of Cut Maximum (APMX) | 5.994 mm | Cutting Direction (HAND) | Right Hand |
| Overall Length (OAL) | 101.6 mm | Measurement Type | Metric |
| Ramping Angle Maximum (RMPX) | 2 Degrees | Body Material | Steel |
| Application | | Facing | Helical Interpolation | Rampdown | | Protruding Length (LPR) | 44.45 mm |
| Connection Diameter Machine Side (DCONMS) | 25.4 mm | Connection Code Machine Side (CCMS) | Cylindrical |
| Weight of Item (WT) | 0.73 Kg | Cutting Diameter Maximum (DCX) | 24 mm |
Product Features
| Family Description | Reliable performance, strength & economy! | Country of Origin | Usa |
Shipping Info
Package Weight
0.002
