1TG1F032040X8R00
.040″ Max. depth of cut Three different insert edge preparations provide application flexibility Excellent high feed performance & economy!
| Cutting Diameter (DC/DCX) | 32 mm | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Diameter (DC) | 24.3 mm | Tool Cutting Edge Angle (KAPR) | 90 Degrees |
| Cutting Item Count (CICT) | 5 | Cutting Direction (HAND) | Right Hand |
| Depth of Cut Maximum (APMX) | 1 mm | Measurement Type | Metric |
| Ramping Angle Maximum (RMPX) | 1 Degrees | Body Material | Steel |
| Application | | Facing | Helical Interpolation | Rampdown | Slotting | | Connection Code Machine Side (CCMS) | Cylindrical |
| Weight of Item (WT) | 0.73 Kg | Cutting Diameter Maximum (DCX) | 32 mm |
| Functional Length (LF) | 40 mm |
Product Features
| Family Description | .040″ Max. depth of cut Three different insert edge preparations provide application flexibility Excellent high feed performance & economy! | Country of Origin | Usa |
Shipping Info
Package Weight
0.573
