| Type | Rigid Tapping Collet | Coolant Supply Property (CSP) | Coolant Thru |
| Style | Tapping collet GB | Connection Diameter Maximum Workpiece Side (DCONXWS) | 7.1 mm |
| Connection Diameter Machine Side (DCONMS) | M7 | Measurement Type | Metric |
| Shank Size (SS) | ER32 | Square Size | 5.6 mm |
Product Features
| Remarks | •GB Tapping Collet
•Interchangeable, with standard ER collet DIN 6499/ISO 15488
•No additional toolholders and clamping nuts necessary
•Wide product range, sizes: ER-GB 11 to 50
•Standards: DIN, ISO, JIS and ANSI
•Square for tight grip of tap, eliminates tap slippage in collets | Country of Origin | Switzerland |
Shipping Info
Package Weight
.250
