3/32″ Dia-2-1/2″ OAL-Long FL/ Long Shank- SQ SE-AD-CBD EM-3FL
| Cutting Diameter (DC) | 3/32″ | Flute Count (NOF) | 3 |
| Connection Diameter Machine Side (DCONMS) | 1/8″ | End Shape | Square |
| Depth of Cut Maximum (APMX) | 3/4″ | Tool Type | Single-End |
| Overall Length (OAL) | 2-1/2″ | Length Group | Long Flute|Long Shank |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.09375″ |
| Coating | Amorphous Diamond |
Product Features
| Remarks | •35° Helix
•Diameter tolerance: +.000″/-.001″(except as noted)
•AD (Amorphous Diamond) coated "G" Mills are specifically designed for machining graphite electrodes.
•"G" Mills have been shown to be a cost effective solutions in producing graphite electrodes by lowering tooling costs and improving productivity.
•Designed with a Fast Helix and 3- or 4- flute design, "G" Mills outperform conventional end mills by providing faster particle evacuation while producing extremely smooth finishes in graphite.
•"G" Mills are factory laser inspected to ensure more accurate machining of graphite electrodes. | Country of Origin | USA |
Shipping Info
Package Length
3.16000
Package Width
.12000
Package Weight
.0099
