| Cutting Width (CW) | 0.118″ | Application | | Int. Groove & Turn | Int. Grooving | |
| Corner Radius (RE) | 0.016″ | Cutting Direction (HAND) | Neutral |
| Cutting Depth Maximum (CDX) | 0.0059″ | Number of Cutting Edges | 2 |
| Clearance Angle Major (AN) | 14 Degrees | Insert Seat Size Code (SSC) | 3 |
| Insert Thickness (S) | 0.185″ | Series/List # | TDIT300E040 |
| Insert Length (INSL) | 0.787″ | Measurement Type | Inch |
| Coating | TiCN | Body Material | Carbide |
| Grade | TT7220 |
Product Features
Family Description
T-type Chipbreakers
Country of Origin
S.Korea
Shipping Info
Package Length
3.56000
Package Width
1.35000
Package Height
.33000
Package Weight
.008
