| Insert Style | TNMG | Min D.O.C. | 0.031″ |
| Corner Radius (RE) | 0.016″ | Depth of Cut Maximum (APMX) | 0.138″ |
| Insert Size | 2.531 | Min. Turning Feed (ft(min)) | 0.004″ |
| Cutting Edge Length (L) | 0.541″ | Max. Turning Feed (ft(max)) | 0.014″ |
| Insert Thickness (S) | 0.187″ | Number of Cutting Edges | 6 |
| Inscribed Circle Diameter (IC) | 0.313″ | Cutting Direction (HAND) | Neutral |
| Insert Included Angle (EPSR) | 60 Degrees | Measurement Type | Inch |
| Coating | TiCN+Al2O3 | Series/List # | TNMG 2.531-MT |
| Grade | TT5100 | Body Material | Carbide |
Product Features
Country of Origin
S.Korea
Shipping Info
Package Weight
.013
