| Insert Style | DCGT | Min D.O.C. | 0.004″ |
| Corner Radius (RE) | 0.004″ | Depth of Cut Maximum (APMX) | 0.1″ |
| Insert Size | 32.5 | Min. Turning Feed (ft(min)) | 0.0005″ |
| Cutting Edge Length (L) | 0.457″ | Max. Turning Feed (ft(max)) | 0.004″ |
| Insert Thickness (S) | 0.156″ | Clearance Angle Major (AN) | 7 Degrees |
| Inscribed Circle Diameter (IC) | 3/8″ | Number of Cutting Edges | 2 |
| Insert Included Angle (EPSR) | 55 Degrees | Cutting Direction (HAND) | Neutral |
| Coating | TiAlN+AlTiN+TiAlN+TiN | Measurement Type | Inch |
| Grade | TT5080 | Series/List # | DCGT3250SA |
| Fixing Hole Diameter (D1) | 0.173″ | Body Material | Carbide |
Product Features
Country of Origin
S.Korea
Shipping Info
Package Weight
.012
