3/8 DX5/16 SHANKX.015 R-4FL-ALTIN
| Cutting Diameter (DC) | 3/8″ | Corner Radius (RE) | 1/64″ |
| Connection Diameter Machine Side (DCONMS) | 5/16″ | Length Group | 1.5D |
| Depth of Cut Maximum (APMX) | 0.563″ | Flute Type | Spiral |
| Overall Length (OAL) | 4″ | Body Material | Carbide |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.375″ |
| Coating | AlTiN | Measurement Type | Inch |
| Flute Count (NOF) | 4 | Shank Size (SS) | 5/16″ |
| Flute Helix Angle (FHA) | 30 Degrees | Corner Radius (RE) / Chamfer Width (CHW) | 1/64″ |
| Shank Type | Round | Cutting Direction (HAND) | Right Hand |
| End Shape | Corner Radius | Single / Double End | Single End |
| Usable Length (LU) | 0.563″ |
Product Features
| Country of Origin | USA |
Shipping Info
Package Weight
.160
