| Insert Style | CNMG | Depth of Cut Maximum (APMX) | 0.079″ |
| Corner Radius (RE) | 0.016″ | Min. Turning Feed (ft(min)) | 0.003″ |
| Insert Size | 431 | Max. Turning Feed (ft(max)) | 0.008″ |
| Cutting Edge Length (L) | 0.508″ | Number of Cutting Edges | 4 |
| Insert Thickness (S) | 0.187″ | Cutting Direction (HAND) | Neutral |
| Inscribed Circle Diameter (IC) | 1/2″ | Measurement Type | Inch |
| Insert Included Angle (EPSR) | 80 Degrees | Series/List # | CNMG431FG |
| Grade | PV3010 | Body Material | Carbide |
| Min D.O.C. | 0.02″ |
Product Features
Country of Origin
S.Korea
Shipping Info
Package Weight
.012
