.500 DX.020R CRAD EM-4FL
SQ End Mill; 1/2″ Dia. × 1″ LOC × 1/2″ Shank Dia. × 3″ OAL ; 4 FL ; Carbide ; Uncoated
| Cutting Diameter (DC) | 1/2″ | Corner Radius (RE) | 0.02″ |
| Connection Diameter Machine Side (DCONMS) | 1/2″ | Length Group | 2D |
| Depth of Cut Maximum (APMX) | 1″ | Flute Type | Spiral |
| Overall Length (OAL) | 3″ | Body Material | Carbide |
| Cutting Edge Material | Carbide | Decimal Equivalent | 0.5″ |
| Coating | Uncoated | Measurement Type | Inch |
| Flute Count (NOF) | 4 | Shank Size (SS) | 1/2″ |
| Flute Helix Angle (FHA) | 30 Degrees | Corner Radius (RE) / Chamfer Width (CHW) | 0.02″ |
| Shank Type | Round | Cutting Direction (HAND) | Right Hand |
| End Shape | Corner Radius | Single / Double End | Single End |
| Usable Length (LU) | 1″ |
Product Features
| Country of Origin | USA |
