QR0500150N7R02
Extended Length Shank For Maximum Clamping Surface Ideal For Lathe Applications Note: Brass coolant fitting should be ordered separately
| Cutting Diameter (DC) | 1.969″ | Cutting Diameter Maximum (DCX) | 2.009″ |
| Usable Length (LU) | 5.91″ | Flange Diameter (DF) | 2.362″ |
| Application | | Drill Mill | Drilling | | Point Length (PL) | 0.084″ |
| Connection Diameter Machine Side (DCONMS) | 1-1/2″ | Measurement Type | Inch |
| Shank Length (LS) | 3.16″ | Length Group | 3D |
| Functional Length (LF) | 7.48″ | Effective No. of Teeth | 1 |
| Overall Length (OAL) | 10.63″ | Body Material | Steel |
| Cutting Item Count (CICT) | 2 | Decimal Equivalent | 1.969″ |
Product Features
Family Description
Extended Length Shank For Maximum Clamping Surface Ideal For Lathe Applications Note: Brass coolant fitting should be ordered separately
Country of Origin
S.Korea
Shipping Info
Package Weight
5.180
