QR0325163N6R02
Extended Length Shank For Maximum Clamping Surface Ideal For Lathe Applications Note: Brass coolant fitting should be ordered separately
| Cutting Diameter (DC) | 1.281″ | Flange Diameter (DF) | 1.772″ |
| Usable Length (LU) | 6.41″ | Point Length (PL) | 0.066″ |
| Application | | Drill Mill | Drilling | | Measurement Type | Inch |
| Connection Diameter Machine Side (DCONMS) | 1-1/4″ | Length Group | 5D |
| Shank Length (LS) | 3.16″ | Effective No. of Teeth | 1 |
| Functional Length (LF) | 7.87″ | Body Material | Steel |
| Overall Length (OAL) | 11.02″ | Decimal Equivalent | 1.281″ |
| Cutting Item Count (CICT) | 2 |
Product Features
Family Description
Extended Length Shank For Maximum Clamping Surface Ideal For Lathe Applications Note: Brass coolant fitting should be ordered separately
Country of Origin
S.Korea
Shipping Info
Package Weight
2.932
