Cutting Diameter (DC) | 12 mm | End Shape | Square |
Connection Diameter Machine Side (DCONMS) | 12 mm | Grade | IM250 TaC |
Depth of Cut Maximum (APMX) | 42 mm | Tool Type | Single End |
Overall Length (OAL) | 93 mm | Coolant Supply Property (CSP) | External |
Cutting Edge Material | Carbide | Body Material | Carbide |
Coating | Uncoated | Style | 3.5xD |
Flute Count (NOF) | 5 | Measurement Type | Metric |
Flute Helix Angle (FHA) | 35 Degrees | Series/List # | APC5-SQ |
Shank Type | Round | Shank Diameter Tolerance (TCDMM) | h6 |
Product Features
Remarks | •Benefit from the unique Chip Management System (CMS).•CMS breaks up long, stringy chips, which eliminates recutting chips and chip packing and allows for deep, free cutting tool movement in aluminum.•The results are great chip control and very high metal removal rates. | Country of Origin | Usa |
Shipping Info
Package Weight
0.290
